120 Series Top Plate Swivel Caster with 6 x 2 White Polypropylene RW - Polypropylene (Retort) Wheel and Stainless Steel Face Brake
120 Series Top Plate Swivel Caster with 6 x 2 White Polypropylene RW - Polypropylene (Retort) Wheel and Stainless Steel Face Brake

Albion

120 Series Top Plate Swivel Caster with 6 x 2 White Polypropylene RW - Polypropylene (Retort) Wheel and Stainless Steel Face Brake

View CAD
SKU: 120RW06241SFBG
Hurry up! Current stock:
Technical Data
Series 120 Series
Caster Type Swivel
Brake Type Stainless Steel Face (FBG)
Wheel Diameter 6
Tread Width 2
Wheel Type RW - Polypropylene (Retort)
Wheel Color White Polypropylene
Bearing Type Plain Bore
Fastening Type Top Plate Swivel
Fastening Size 4-1/2" x 4"
Capacity 700
Mount Height 7.5
Swivel Radius 7.1875
Swivel Lead 1.5625
Swivel Lock None
Wheel Face Moderate crown
Temperature Range -20°F degrees up to +290°F
Hardness 75 Shore D
Wheel Material Polypropylene
Wheel Category High-Temp Polypropylene
Features
Applications
Downloads

CAD

Interact and Download Native CAD models below. Rotate, zoom in/out, and see critical dimensions by utilizing your mouse.

Login required to download CAD
